Схемы электрических соединений – Инструкция по эксплуатации Graco Fine Finish HVLP 9.5
Страница 13
Схемы электрических соединений
313425G
13
Схемы электрических соединений
2
5
3
6
BK
W
G
GROUND
N
L
G
L
G
N
ti12765a
110V
5
10
3
4
7
1
8
12
16
2
9
6
Ref Part
Description
Qty
1
244273 Conductor, BK
1
2
15W486 Conductor, BK
1
3
15W485 Conductor, G/Y
1
4
15W484 Conductor, W
1
5
257333 Conductor, W, BK, G
1
6
240256 Conductor, W
1
7
114064 Plug, inlet
1
8
114403 Circuit Breaker, 15A
1
9
15V923 Plug, outlet, CompPack
1
10 114280 Light, indicator, 120V
1
11 120660 Switch, rocker
1
12 114279 Sensor, pressure
1
ЗАЗЕМЛЕНИЕ
2
5
3
6
GROUND
N
L
G
LG
LINE
G
L1
L2
L2
LOAD
L
G
N
BK
W
G
ti12770a
Ref Part
Description
Qty
1
244273 Conductor, BK
1
2
15W486 Conductor, BK
1
3
15W485 Conductor, G/Y
1
4
15W484 Conductor, W
1
5
257333 Conductor, W, BK, G
1
6
15W488 Conductor, W
1
7
15W487 Conductor, BK
1
8
240558 Conductor, G/Y
1
9
240256 Conductor, W
1
10 114064 Plug, inlet
1
11 16A348 Circuit Breaker, 8A
1
12 15V923 Plug, outlet, CompPack
1
13 114286 Light, Indicator, 240V
1
14 120660 Switch, rocker
1
15 114279 Sensor, pressure
1
16 116168 Filter, suppression
1
3
10
15
8
4
6
7
9
14
16
11
2
12
13
5
1
240V
ЗАЗЕМЛЕНИЕ
