59 GW28-018_v01
Do not leave the appliance unattended when it is connected to a mains –
supply outlet or it is hot.
The appliance is not intended to be operated by means of an external –
timer or separate remote-control system.
The iron is not to be used if it has been dropped, if there are visible signs –
of damage or if it is leaking.
If you do not use the iron, even for short time, switch it off, turning – Tem-
perature Dial (1) in anti-clockwise direction to „MIN” and press power
button (12) at control panel.
Never iron and clothes or fabrics that are being worn by human or pets. –
Never direct the steam to human or pets. –
Hints for ironing
1. Sort out the articles to be ironed according to the type of fabric. This
will minimize the frequency of temperature adjustment for different gar-
ments.
2. Test ironing a small area on the backside or inside the garment if you
are unsure about the type of fabric. Start with a low tempera-ture and
increase gradually.
3. Wait for about three minutes before ironing heat sensitive fabrics. Tem-
perature adjustment needs certain time to reach the required level no
matter it is higher or lower.
4. Delicate fabrics such as silk, wool, velour, etc. are best ironed with an
ironing cloth to prevent shine marks.
5. Read the garment labels and follow the manufacturer’s ironing in-
structions which are often shown by symbols similar to the follow-
ing:
Temperature settings
○ Acetate
○ Elastics
○ Polyamide
○ Polypropylene
○ Polyester ○ Viscose
○ Silk ○ Wool
○ Triacetate
○ Cotton
○ Linen
Technical data
The iron technical parameters are included at the name plate. The steam
generator is I class appliance, equipped with supplying cord and plug with
grounding.
ZELMER iron meets the requirements of effective standards.
The appliance meets the requirements of the following directives:
– Low Voltage Device (LVD) – 2006/95/EC.
– Electro- Magnetic Compatibility (EMC) – 2004/108/EC.
The product is marked with CE symbol on the name plate.
Get to know your steam generator
The appliance has a high technology low-pressure steam chamber that can
be heated up in short time. Water is converted to steam vapour in the cham-
ber and transported to the iron unit through the supply cord.
A. Iron
1. Temperature dial
2. Dial pointer
3. Burst of steam button
4. Control light
5. Cord grommet
B. Base
6. Heat insulation board
7. Base
8. Water tank
9. Anti-calc cartridge
10. Cable support
