2
En
■Using as center speaker
Place the speaker on a TV rack or other stable surface. To prevent
the speaker from falling down, attach the fasteners provided in
each corner of the speaker’s underside.
■To mount the speakers on a wall by using
the attached mounting bracket
Fasten screws into a firm wall or wall support as shown in the
figure, and hang the holes of the mounting bracket on the
protruding screws.
Note
Placing this unit too close to a CRT TV set might impair
picture color or create a buzzing noise. Should this happen,
move the speaker away (more than 20 cm (7-7/8”)) from the
TV set.
When using a PDP or LCD TV, it would not happen.
WARNING
• NS-C210 weighs 2 kg (4 lbs. 7 oz.). Do not mount it on thin
plywood or a wall with soft surface material. If mounted,
the screws may come out and the speaker may fall. This may
damage the speaker, or cause personal injury.
• Do not touch the adhesive surface after peeling off the seal
as this will weaken its adhesive strength.
• Thoroughly wipe clean the surface where the fasteners are
to be attached. Note that adhesive strength is weakened if
the surface is dirty, oily or wet, and that this may cause the
center speaker to drop.
• Do not install the speaker on a wall with nails, adhesives, or
any other unstable hardware. Long term use and vibrations
may cause it to fall.
• To avoid accidents resulting from tripping over loose
speaker cables, fix them securely to the floor or wall.
For NS-C210
Fastener
Make sure that the screws are secured in the
narrow sections of the holes.
292 mm
(11-1/2”)
Diameter. 3.5 to 4 mm
(1/8” to 3/16”)
3 mm
(1/8”)
Min.
20 mm
(13/16”)
Tapping screw
(Available at the hardware store)
Wall or wall
support
