14.3 Registering the Lossnay Unit with the Lossnay
M-NET Remote Controller
Initial registration mode operation
A Lossnay unit must be registered with the Lossnay M-NET remote controller in a group arrangement. Register a Lossnay unit
using the initial registration mode as shown below. In addition, the initial registration mode can be used to search for a Lossnay
unit registered to the group or to delete a registration.
3
@5
A
mitsubishi
e
-
1
©
-4
-6
Setting Procedure
© Turn off the unit.
(Perform the following operation after “HO” flashes on the display.)
® Hold down bot^ ^€1 and I
f
'
lteR
for more than 2 seconds.
This starts the initial registration mode and the set Lossnay M-NET remote controller address flashes on the display.
© Press |3$€l to select the address of the Lossnay unit that you wish to register with this Lossnay M-NET remote controller.
After the button is pressed once, the Lossnay M-NET remote controller address and then the Lossnay unit
address is displayed. Afterwards, each press of the button increase the Lossnay unit address by 1 as shown
below. Holding down the button changes the address more quickly.
[101^ [------------- ^[001]
(Set Lossnay M-NET remote controller address)
^
____
Flashes
[002]
[098^i- [099]
® When the address of the Lossnay unit that you wish to register is displayed, press Si"
If the registration is completed correctly, the display appears as shown below.
to begin registering.
nn 1
LIU 1
/ /
/_
!_
The Lossnay unit type,
“LC”, is displayed.
If the registration is not completed correctly, ^0 ” flashes in the display. Check that the selected Lossnay unit address and
the wiring are correct.
In the case of LGH-150/200RX3-E, there are 2 circuit boards installed in each unit. Because of this, set a separate address
for each of the circuit boards, and register both of those addresses at the remote control.
® After registering, hold down bot^ ^€1 and I
filteR
for more than 2 seconds to end the initial registration mode and the nor
mal display appears.
