ENGLISH
27 Video Output Socket [®] (-> 68,136)
28 Audio Output Socket [®] (-> 68,136)
29 Finder (-> 46, 76)
Due to limitations in LCD production technology, there
may be some tiny bright or dark spots on the Finder
screen, the whole screen may have a slight colour cast,
and flickering may occur. However, this is not a
malfunction and does not affect the recorded picture.
30 Cover of the Button-type Battery’s Compartment
[BACKUP BATTERY] (-> 50)
31 DC Input Socket [DC IN] (-> 18)
32 Battery Eject Lever (<1 BATTERY EJECT] (-♦ 24)
33 Recording Start/Stop Buttons (-> 54, 56)
Use either of these buttons depending on the recording
angle.
34 Otf/On Mode Selector Switch [CAMERA/OFF/VCR]
(^ 24, 56,
66
, 76)
35 Grip Belt (-> 46)
36 Cassette Eject Buttons EJECT] (-> 40)
37 Date/Time/Titte Button [DATE/TITLE] (-> 54,122)
38 Zoom Lever [W/T] (-> 62,
88
)
39 Eyepiece Corrector Lever {-> 46)
40 Shoulder Strap Holders (-> 48)
41 Tripod Receptacle
42 Lens Cap (-> 46, 102)
43 Lens Cap Holder (-> 46)
