ENGLISH
Attaching the Charged Battery
1
Insert the Battery with its top (the end
with the Charge Confirmation Marker)
into the top Battery Holder.
2
Press the bottom of the Battery toward
the Movie Camera until it locks with a
click.
•The remaining battery power can be confirmed
with the Remaining Battery Power Indication O
displayed in the Finder.
• After attaching the Battery, the Remaining
Battery Power Indication briefly indicates a fully
charged Battery regardless of the actual charging
condition. After a few seconds, it indicates the
actual remaining battery power.
•When the Battery is exhausted, the [
]
Indication flashes and the Movie Camera
automatically turns off.
Removing the Battery
Turn in the [POWER] Switch to turn the
Movie Camera off.
Hold the Battery firmly to prevent it
from dropping and pull it off while
sliding the [◄ BATTERY EJECT] Lever
in the direction of the arrow.
22
