User’s Guide
EMS 1.7R
24
*NOTE: While erasing the transmitter codes with function 3 2 the main unit code is also
being erased from the transceivers’ memory (if the transceivers are within the communication
range). This procedure takes about 8 second. After the erasing is completed the main unit code
will be re written down to memory of the transceiver, which was used in erasing procedure, to
reinstate the pager function. Two flashes of the indicator icon on the LCD screen will confirm
the main unit code is written down the transceiver memory.
If you do not want to wait the end of the procedure, exit the function (or programming) at
any time and repeat the Remote Code Learning as described above.
User Software Switches
SSW
Software Switch Function
Default
Button 1
Button 2
#
(LED ON)
(LED OFF)
1 1
Passive ARM Mode
OFF
ON
OFF
1 2
Lock with Passive Arm
OFF
ON
OFF
1 3
Auto Re arming
ON
ON
OFF
1 4
Ignition Safety Door Lock
ON
ON
OFF
1 5
Siren Chirp ON/OFF
ON
ON
OFF
2 2
2 way Handset Alarming on Disarming
OFF
ON
OFF
2 3
All transceiver Page
OFF
ON
OFF
2 4
Passive Arming Immobiliser
OFF
ON
OFF
2 6
Door Operated Car Jacking Mode ON/OFF
OFF
ON
OFF
2 7
Pre warn sensor zone triggered indication on the transceiver
ON
ON
OFF
3 1
PIN Access 1
÷9 (button 2 only) or
1
Press 1 9 times to set Press 1 9 times to set
11
÷99 Digit Code (button 1 and button 2)
Tens Digit of
Units Digit
PIN Code
PIN Code
3 2*
Erase OTHER transmitter Codes (Save code of Remote Being Used)
On Together
3 3
Return User Software Switches to Default
On Together
3 4
Passive Immobiliser Disarm Button
Button1
Press both buttons (1 and 2) together to enter the setting.
Press both buttons once more to exit.
3 5
Passive Immobiliser Trigger Period
OFF
OFF
LED Indication:
15 seconds – LED single flashes
30 seconds – LED double flashes
60 seconds – LED threefold flashes
3 6
Entry Alarm Delay
OFF
OFF
LED Indication:
15 seconds – LED single flashes
30 seconds – LED double flashes
4 6
Move to Installer Switches
On Together
Cycle the ignition off/on after simultaneous pressing of buttons
1 and 2 to move to Installer Software Switches Settings.
Press buttons in one of the following
sequence: 1; 2; 3; 4; 1
⇒1; 1⇒2; 1⇒3;
1
⇒4; 2⇒1; 2⇒2; 2⇒3; 2⇒4; 3⇒1;
3
⇒2; 3⇒3; 3⇒4; 4⇒1; 4⇒2; 4⇒3;
4
⇒4;
Press Button
required number of
times:
1 time – in 15 s
2 times – in 30 s
3 times – in 60 s
Press Button
required number of
times:
1 time – for 15 s
2 times – for 30 s
Автомобильная охранная система “MONGOOSE” Модель EMS 1.7R
29
РУССКИЙ
Сработал датчик удара
Индикатор часов
Замки дверей заперты
Замки дверей открыты
Включен режим
энергосбережения
Двигатель заведен (Охрана с
заведенным двигателем)
Открыта дверь
Открыт капот
Открыт багажник
Разряжен элемент питания
Включено зажигание
Передача команды
Valet режим
Тестовый режим
Включена функция
блокировки кнопок пульта
Таймер парковки
Режим Anti Hi jack
Режим охраны включен
Режим охраны выключен
Не используется
