Two Way Car Alarm System MONGOOSE EMS 1.7R 21
ENGLISH
Number 0f Transmitters Learnt Flashes
1 1
2 2
3 3
4 4
Zone By Pass
If a door, hood, trunk or sensor triggers the alarm system eight times in succession during one
armed period the alarm system will then ignore any further signals from that sensor. All other
sensors and the starter kill will remain activated when the sensor is by passed.
LED Display of Transmitters Learnt
Every time the ignition is switched on the LED will flash in a sequence to indicate the
number of transmitters learnt to the alarm system memory. Three full sequences of flashes will
be repeated.
NOTE: If the LED provides the Anti Hi jack or Passive Immobiliser or Trigger memory
indication the Display of Transmitters Learnt will be performed after the Anti Hi jack or the
Passive immobiliser is exited or three full sequence of the Trigger Memory indication is completed.
Pager Test
Once button 3 is pressed with the alarm system armed or armed with the engine running a
Pager Test feature for current armed period will be included, 5 minutes after you press button 3,
the system will transmit a test signal to the Hand Held Transceiver to test the range of the pager
system. The pager test indication will last for 2 minutes. You can cancel the Pager Test indication
before 2 minute period is over by pressing any button of the Handset. This Pager Test will be
available as many times as you press button 3 within the armed period (one activation for each
pressing).
When the transceiver receives a test signal the Pager Test icon will be displayed on
the LCD panel, the pager test melody will be sounding, and all symbols will be
displayed on the LCD panel one after another.
Auxiliary Outputs
Trunk Release Output
Pressing button 2 for 3 seconds activates the Trunk Release output. This will issue an impulse
on the trunk release output wire and will override the sensors and trunk input until 10 seconds
after the trunk switch is closed.
Руководство пользователя
EMS 1.7R
32
Однонаправленный пульт дистанционного управления
сигнализацией.
Миниатюрный радиопередатчик, питающийся от 12 вольтовой батарейки (тип 23 А),
которой хватает примерно на 1 год эксплуатации. Существенное снижение дальности
приема системой команд передатчика говорит о необходимости замены батарейки. На
брелоке расположены две кнопки управления и индикаторный светодиод. Алгоритм
формирования и передачи управляющих команд идентичен двунаправленному пульту
управления. Однонаправленный пульт предназначен только для управления сигнализа
цией.
кнопка 1
кнопка 2
