Installation
/f\ Warning
Remove lower
cover
Remove the
freezer
compartment
door
Remove the
refrigerator
door
Pass the
refrigerator
Door removal
Electric Shock Hazard
Disconnect electrical supply to refrigerator before installing.
Failure to do so could result in death or serious
injury.
If your access door is too narrow for the
refrigerator remove the refrigerator door and
pass the refrigerator laterally.
Remove the lower cover by lifting upward.
1) Loosen the hinge cover screws and remove
the cover.
2) Remove the keeper by rotating it to counter
clockwise (®) and then lifting the upper
hinge up{ (2)).
3) Remove the freezer compartment door by
lifting it upward.
1) Loosen the hinge cover screws and remove
the cover. Remove connection wire,if any,
except for the earth line.
2) Remove keeper by rotating it clockwise (®)
and then remove the upper hinge by
lifting it up ((D).
3) Remove the refrigerator compartment door by
lifting it up.
Pass the refrigerator laterally through access
door as shown in the right figure.
O
