Care and maintenance
Freezer
compartment
lamp
Freezer
compartment
shelf
Door rack and
support
Lamp in
refrigerator
compartment
Refreshment
center
Vegetabie
compartment
cover
How to dismantle parts
NOTE
' Dismantling is done in the reverse sequence of assembly.
Be sure to unplug the power plug before dismantling and assembly.
Never apply severe force to dismantle parts. Parts may be damaged.
Separate the lamp by pulling it out® while slightly
pressing ® and rotating ® the lamp cover.
Turn the bulb counterclockwise. Use a 40-watt bulb
(max.) which can be purchased at a service
center.
To remove a shelf, push the shelf to the left
lift the left part of the shelf a bit ®, lift the right
part up @, and take it out.
Lift the door rack to®direction holding both
sides and pull it out to @ direction.
Insert the tool into the marked area (®) and
push the tool to disconnect.
Use the tool with the flat tip such as (-) screw
driver.
Turn the bulb counterclockwise. Max. 40 W
bulb for refrigerator is used and can be
purchased at a service center.
Separate the bin (®) to upward.
Separate the upper rack of the refreshment
center and then pull out the refreshment
center cover (@).
The refreshment center can be removed
by pulling it upwards.
imr
IMMMM IMIMMI
t
®
^lt®
«
NOTE
• Be sure to remove parts from the refrigerator door when removing the vegetable
compartment and snack corner.
To remove the vegetable compartment cover,
pull out the vegetable compartment a bit to
the front®, lift the front part of the vegetable
compartment cover as shown by®, and take
it out.
