ENGLISH
3
resume to recording mode press this button
once again.
7. To stop press the STOP/EJ button. When the
cassette is recorded completely, the record
will stop automatically.
RECORD FROM OTHER SOURCES
You can record from other sources, for instance
from CD disc or USB device. Switch on the de-
sired source and follow instructions in the chap-
ter RECORD FROM RADIO.
USB DEVICES
. Switch on the cassette recorder, by pressing
the POWER button.
2. To select the USB mode, press successively
the FUNCTION button, until the “USB”
indication appears on the LCD display.
3. Insert the USB device (for example, portable
МРЗ player or flash memory) into the USB
jack (39, pic. ). Number of folders and
tracks will appear on the LCD display.
Note: if neither portable MP3 player nor flash
memory device is connected to the USB “NO
DEV” will appear on the LCD display.
. To playback press the PLAY/PAUSE button.
5. Control buttons and order of operations
while using USB are the same as those of
a МР3 disc. Follow the instructions in the
chapter PLAYING MP3 DISCS.
SD memory cards
. Switch on the cassette recorder by pressing
the POWER button.
2. To select the SD mode, press successively
the FUNCTION button, until the “SD”
indication appears on the LCD display.
3. Insert a SD/MMC card into the jack (0, pic.
). Number of folders and tracks will appear
on the LCD display.
.
Note: if no SD/MMC card is connected to the
jack (0, pic. ) “NO SD” will appear on the LCD
display.
5. To playback press the PLAY/PAUSE button.
6. Control buttons and order of operations
while using memory card are the same as
those of a МР3 disc. Follow the instructions
in the chapter PLAYING MP3 DISCS.
Specifications
Power consumption 25W
Power supply AC 230V
Dimensions L 422 X W 240
X H 167 mm
Output Speakers RMS: 3.5Wx2CH
Speakers 1. Big Speaker: 4
Ohm, 4-Inch,
5W x2pcs
2. Small speaker:
8ohm, 2-Inch
0.5Wx2pcs
3. Buzzer plate: Dim.
20mmx2pcs
Battery Units :UM-1, ‘D’ x8pcs
Backup : ‘AA’ X3pcs
Remote: ‘AAA’ X2pcs
СD:
Frequency band
20Hz~20kHz
S/N ratio 60dB
FM/MW (AM):
Frequency band
FM: 65~108MHz
AM: 522~1620kHz
Intermediate frequency FM IF:10.7MHz
Antenna FM: Rod Antenna
AM: Built in FERRITE
CORE
