10
English
Replacingthesystemouterfoilandtheinner
blades
system outer foil once every year
inner blade once every two years
Replacingthesystemouterfoil
1. Press the system outer foil release
buttons and lift the system outer foil
upwards as illustrated.
. Insert the system outer foil by pushing it
downwards until it clicks.
1
Replacingtheinnerblades
1. Press the foil frame release buttons and
lift the outer foil section upwards as
illustrated.
. Remove the inner blades one at a time as
illustrated.
Do not touch the edges (metal parts) of
the inner blades to prevent injury to your
hand.
. Insert the inner blades one at a time until
they click as illustrated.
•
1
3 2


Cleaningwiththebrush
1. Clean the inner blades using the short
brush by moving it in direction (A).
Clean the system outer foil, the shaver
body and the trimmer using the long
brush.
Do not move the short brush in
direction (B) as it will damage the inner
blades and affect their sharpness.
Do not use the short brush to clean the
outer foils. •
•
(A) (B)
Cleaningtheself-cleaningrecharger
Beard trimmings may become attached to the cleaning tray of the
self‑cleaning recharger. Follow the steps below to remove them.
We recommend doing this each time you change the detergent
cartridge.
1. Be sure to remove the water tank and
the appliance plug from the self‑
cleaning recharger.
Be careful not to spill the cleaning
liquid. •
1
