English - 7
1 COMMON INTERFACE Slot
Insert CI (Common Interface) card into the slot.
(refer to page 24)
When not in - serting CI CARD in some channels,
Scramble Signal is displayed on the screen.
The - pairing information containing a telephone number,
CI CARD ID, Host ID, and other information will be
displayed in about 2~3 minutes. If an error message is
displayed, please contact your service provider.
When the channel - information configuration has finished,
the message Updating Completed is displayed,
indicating that the channel list is now updated.
Insert the CI-Card in the direction marked on it. N
’CI(CI+) CARD’ is not supported in some countries, N
regions, broadcasting stations check with your authorized
dealer.
2 HDMI IN 4
Connect to the HDMI jack of a device with HDMI output.
3 USB
Connect a USB mass storage device to view and play photo
files (JPEG) and audio files (MP3).
4 AV IN (VIDEO, AUDIO L/R)
Video and audio inputs for external devices, such as a
camcorder or VCR.
The product colour and shape may vary depending on the model. N
TV Side Panel
2
4
1
3
