English - 13
Cable Search Option
❑
You can add directly the channel search range in the network search mode. (Dependingon the each country)
Frequency (Start~Stop)
•
: Displays the frequency for the channel.
Modulation
•
: Displays available modulation values.
Symbol Rate
•
: Displays available symbol rates.
Set the
N
Frequency (Start~Stop) and Symbol Rate using the number (0~9) buttons.
Now & Next Guide / Full Guide
❑
The EPG (Electronic Programme Guide) information is provided by the broadcasters. Programme entries may appear blank or out
of date as a result of the information broadcast on a given channel. The display will dynamically update as soon as new information
becomes available.
Now & Next Guide
•
: For the six channels indicated in the left-hand column, displays the Current programme and the Next
programme information.
Full Guide
•
: Displays the programme information as time ordered One hour
segments. One hours of programme information is displayed which may be scrolled
forwards or backwards in time.
Default Guide
❑
Now/Next / Full Guide
You can decide whether to display either the
Now/Next or the Full Guide when the
GUIDE button on the remote control is pressed.
You can also display the guide menu simply by pressing the
O
GUIDE button.
Using the Now & Next Guide / Full Guide
▲ / ▼ / ◄ / ►
(
ENTER)
Select a programme by pressing the ▲/▼/◄/► button.
If the next progrmme is selected, it is scheduled with the clock icon displayed. If the
ENTERE button is
pressed again, press the ▲/▼/◄/► button to select
Cancel Schedules, the scheduling is canceled with the
clock icon gone.
For details about scheduling programmes, refer to the section.
RED
Toggle between the
Now/Next or Full Guide.
GREEN
Full Guide: Scroll backwards quickly (-24 hours).
YELLOW
Full Guide: Scroll forwards quickly (+24 hours).
BLUE
Exit the guide.
INFO
INFO button for the detailed information. Channel Number, Running Time, Status Bar, Parental Level, Video
Quality Information (HD/SD), Sound Modes, Subtitle or Teletext, languages of Subtitle or Teletext and brief
summary of the highlighted programme are included on the detailed information. “…” will be appeared if the
summary is long.
Channel
❑
Mode
When the press the P (</>) button, Channels will be switched within the selected channel list.
Added Ch.:
Channels will be switched within the memorised channel list.
Favourite Ch.:
Channels will be switched within the favourite channel list.
Fine Tune
❑
(Analogue channel only)
If the reception is clear, you do not have to fine tune the channel, as this is done automatically during the search and store
operation. If the signal is weak or distorted, you may have to fine tune the channel manually.
Fine tuned channels that have been saved are marked with an asterisk
N
* on the right-hand side of the channel number in the
channel banner.
If you do not store the fine-tuned channel in memory, adjustments are not saved.
N
To reset the fine-tuning, select
N
Reset by pressing the ▼ button and then press the ENTERE
button.
Full Guide
DTV Cable 900 f tn 2:10 Tue 1 Jun
Freshmen On Campus
2:00 - 2:30
No Detailed Information
Today
2:00 - 3:00
3:00 - 4:00
Mint Extra
Loaded
Fresh 40 with Dynamite MC
The Distillery
Smash Hits! Sunday
900 f tn
901 ITV Play
902 Kerrang!
903 Kiss
903 oneword
903 Smash Hits!
▼
Street Hypn..
Kisstory
No Information
No Information
No Information
Freshmen O..
Watch
Now/Next
+24 Hours
Exit
Now & Next Guide
DTV Cable 900 f tn 2:10 Tue 1 Jun
Freshmen On Campus
2:00 - 2:30
No Detailed Information
Mint Extra
Loaded
Fresh 40 with Dynamite MC
The Distillery
Smash Hits! Sunday
900 f tn
901 ITV Play
902 Kerrang!
903 Kiss
903 oneword
903 Smash Hits!
▼
Street Hypn..
Kisstory
No Information
No Information
No Information
Freshmen O..
Watch
I
Information
Full Guide
Exit
Now
Next
Channel
Now & Next Guide
Full Guide
Default Guide
: Now/Next
►
Channel List
Channel Mode
: Added Ch.
Fine Tune
