Samsung PS50B550T4W - Инструкция (Страница 12)

English - 12
Storing Channels
Country
❑
Digital Channel
„
: You can change the country for digital channels.
Analogue Channel
„
: You can change the country for analogue channels.
The PIN number input screen appears. Enter your 4 digit PIN number. N
Auto Store
❑
Scans for all channels with active broadcast stations (and availability depends on your
country) and stores them in the TV's memory.
You can memorise the channels of the selected connection.
Air • : Air antenna signal.
Cable • : Cable antenna signal.
You can memorise the channel source
Digital & Analogue • : Digital and Analogue channels.
Digital • : Digital channels.
Analogue • : Analogue channels.
When selecting N Cable
Search Mode • : Displays the search mode. ( Quick)
- Network ID: Displays the network identification code.
- Frequency: Displays the frequency for the channel.
- Modulation: Displays available modulation values.
- Symbol Rate: Displays available symbol rates.
Search Mode • : Displays the search mode.( Full, Network)
- Frequency (Start~Stop): Displays the frequency for the channel.
- Modulation: Displays available modulation values.
- Symbol Rate : Displays available symbol rates.
If you want to stop N Auto Store, press the ENTERE button.
The Stop Auto Store? message will be displayed.
Select Yes by pressing the ◄ or ► button, then press the ENTERE button.
Manual Store
❑
Scans for a channel manually and stores it in the TV’s memory.
Digital Channel
„
(Digital)
Digital Channel is only available in DTV mode. N
Channel • : Set the Channel number using the ▲, ▼ or number (0~9) buttons.
Frequency • : Set the frequency using the number buttons.
Bandwidth • : Set the bandwidth using the ▲, ▼ or number (0~9) buttons.
When it has finished, channels are updated in the channel list. N
Analogue Channel
„
Manual store for analogue channel.
Programme • (Programme number to be assigned to a channel): Sets the programme number using the ▲, ▼ or number ( 0~9)
buttons.
Colour System → Auto / PAL / SECAM / NTSC 4.43 • : Sets the colour system value using the ▲ or ▼ button.
Sound System • → BG / DK / I / L : Sets the sound system value using the ▲ or ▼ button.
Channel • (When you know the number of the channel to be stored): Press the ▲ or ▼ button to select C (Air channel) or S
(Cable channel). Press the ► button, then press the ▲, ▼ or number ( 0~9) buttons to select the required number.
If there is abnormal sound or no sound, reselect the sound standard required. N
Search • (When you do not know the channel numbers): Press the ▲ or ▼ button to start the search. The tuner scans the
frequency range until the first channel or the channel that you selected is received on the screen.
Store • (When you store the channel and associated programme number): Set to OK by pressing the ENTERE button.
Channel mode N
- C (Air channel mode): You can select a channel by entering the assigned number to each air broadcasting station in this mode.
- S (Cable channel mode): You can select a channel by entering the assigned number for each cable channel in this mode.
Channel Control
Continued...
Channel
Country
►
Auto Store
Manual Store
Cable Search Option
Now & Next Guide
Full Guide
Default Guide
: Now/Next
