English - 13
Cable Search Option
❑
You can add directly the channel search range in the network search mode. (Dependingon the each country)
Freq.Start • : Displays the frequency start values.
Freq.Stop • : Displays the frequency stop values.
Modulation • : Displays available modulation values.
Symbol Rate • : Displays available symbol rates.
If the N Freq.Start value is bigger than Freq.Stop value, the warning message is displayed.
Full Guide / Mini Guide
❑
The EPG (Electronic Programme Guide) information is provided by the broadcasters. Programme entries may appear blank or out
of date as a result of the information broadcast on a given channel. The display will dynamically update as soon as new information
becomes available.
Full Guide • : Displays the programme information as time ordered One hour
segments. One hours of programme information is displayed which may be scrolled
forwards or backwards in time.
Mini Guide • : The information of each programme is displayed by each line on the
current channel Mini Guide screen from the current programme onwards according
to the programme starting time order.
Default Guide
❑
Mini Guide / Full Guide
„
You can decide whether to display either the Mini Guide or the Full Guide when the
GUIDE button on the remote control is pressed.
You can also display the guide menu simply by pressing the O GUIDE button.
Using the Full / Mini Guide
▲ / ▼ / ◄ / ►,
ENTER
Select a programme by pressing the ▲/▼/◄/►/ ENTERE button.
RED Toggle between the Mini Guide or Full Guide.
GREEN Full Guide: Scroll backwards quickly (-24 hours).
YELLOW Full Guide: Scroll forwards quickly (+24 hours).
BLUE Exit the guide.
INFO INFO button for the detailed information.
Channel
❑
Mode
When the press the P (</>) button, Channels will be switched within the selected channel list.
Added Ch.:
„ Channels will be switched within the memorised channel list.
Favourite Ch.: „ Channels will be switched within the favourite channel list.
Fine Tune
❑
(Analogue channel only)
If the reception is clear, you do not have to fine tune the channel, as this is done automatically during the search and store
operation. If the signal is weak or distorted, you may have to fine tune the channel manually.
Fine tuned channels that have been saved are marked with an asterisk N * on the right-hand side of the channel number in the
channel banner.
If you do not store the fine-tuned channel in memory, adjustments are not saved. N
To reset the fine-tuning, select N Reset by pressing the ▼ button and then press the ENTERE button.
Channel
Full Guide
Mini Guide
Default Guide : Full Guide ►
Channel List
Channel Mode
: Added Ch.
Fine Tune
Full Guide
DTV Cable 900 f tn 2:10 Tue 1 Jun
Freshmen On Campus
2:00 - 2:30
No Detailed Information
Today 2:00 - 3:00 3:00 - 4:00
Mint Extra
Loaded
Fresh 40 with Dynamite MC
The Distillery
Smash Hits! Sunday
900 f tn
901 ITV Play
902 Kerrang!
903 Kiss
903 oneword
903 Smash Hits!
▼
Street Hypn..
Kisstory
No Information
No Information
No Information
Freshmen O..
Watch Information Page „ Mini Guide „ +24 Hours „ Exit
Mini Guide DTV Cable 900 f tn
Street Hypnosis
Booze Britain
2:00
2:30
5:00 ▼
Freshmen On Campus
Watch Information Page „ Full Guide „ Exit
