Sharp SJ-36JM - Инструкция (Страница 9)

9
Ice storage space
Refrigerator compartment
The refrigerator controls its temperature automatically.
However, if needed, adjust the temperature as follows.
CONTROLLING TEMPERATURES
• If the refrigerator is operated for a long time with REFRIG-
ERATOR TEMP. CONTROL set at 7(Coldest), foods stored
in the refrigerator compartment may also freeze.
• Low ambient temperature may cause placed foods to freeze
even if REFRIGERATOR TEMP. CONTROL is set to 1(MIN).
Freezer compartment
• If the refrigerator is operated for a long time with
FREEZER TEMP. CONTROL set at 7(MAX), foods stored
in the refrigerator compartment may also freeze.
HINTS WHEN MAKING ICE
1. Do not over fill Ice cube trays; otherwise the ice cubes
will be joined together when frozen.
2. When the ice cubes are made, turn the lever clockwise
to empty the ice into Ice storage space of Freezer case.
NOTE:
• To prevent damage to the Freezer case, do not make
ice in the Ice storage space of the Freezer case or pour
oil into it.
• Do not twist the lever while Freezer case is open.
DUAL SWING DOOR
You can take out the foods you want from either side.
NOTE:
• Do not destroy or damage the refrigerator body’s struc-
ture or internal structure intentionally.
• Do not put any objects on the lower hinge or lower hinge
pin.
• Avoid being caught by the lower hinge pin and cam.
• Do not add oil to the refrigerator body, pulley, lower hinge,
since the plastic components will be influenced by differ-
ent kinds of oil.
7(Coldest)
4(MED)
1(MIN)
For keeping foods fresher
tasting.
When the refrigerator does
not provide sufficient cool-
ing.
For normal operation.
When the refrigerator pro-
vides excessive cooling.
(only for SJ-W40JM, SJ-W36JM)
7(MAX)
4(MED)
1(MIN)
For making ice rapidly or
fast freezing.
When frozen food or ice
cream is not stored.
For normal freezing.
Pulley Lower hinge
Lower hinge pin
Cam
3 4 5
MIN
FREEZER TEMP. CONTROL
MAX
2
(Coldest)
Structure of double-hinged
door (Door mechanisms in-
stalled at four corners)
Structure of double-
hinged door (On refrig-
erator body)
OPERATION
Freezer case
Lever
STAINLESS STEEL FREEZER CASE
• To freeze the foods rapidly may prevent the foods from
loosing the nutritive composition during the period of
freezing.
• Using the stainless steel with high thermal conductance,
it can be quick frozen evenly.
• The dirt or peculiar smell are hardly stained to it, it is
very convenient for cleaning.
NOTE:
• Do not touch Stainless steel Freezer case with wet hands.
• Do not pour the water into Stainless steel Freezer case
directly for making ice, it will result in the distortion of
Stainless steel Freezer case.
• Do not put the foods with salt into Stainless steel Freezer
case, it will cause Stainless steel Freezer case to get
rusty.
DEFROSTING
Defrosting is fully automatic due to a unique energy sav-
ing system. Whereby the defrost cycle start time is pro-
portional to the running time of your refrigerator compres-
sor, i. e., the less time the refrigerator compressor oper-
ates (during the winter season or you’re away on holi-
days), the longer the time between each defrost cycle.
MIN
MED
1
2
3
4
5
6
7 Coldest
CHILLED
ZONE
REFRIGERATOR
TEMP.CONTROL
