Sharp SJ-36JM - Инструкция (Страница 8)

8
SJ-40JM, SJ-W40JM SJ-36JM, SJ-W36JM
DESCRIPTION
1. Light
Replacing the lamp bulb
2. Refrigerator shelf
3. Refrigerator temp. control knob
4. Fresh case
The cover of Fresh case
opens as the case is pulled.
5. Lever
The airflow to Fruit and
vegetable crisper can
be controlled by moving
the vent hole lever to the
right or left.
6. Fruit and vegetable crisper
7. Evaporating pan (rear side)
8. Adjustable feet
9. Light switch
10. Free pocket
11. Egg holder
12. Bottle pocket
13. Freezer temp. control knob
14. Ice cube maker
15.
Stainless steel Freezer case
16. Freezer case
17. Magnetic door seal
Lever
Replace the lamp bulb with same type : base E12,
MAX 10W, T-20. Make sure that the rated voltage
and wattage of the lamp bulb are correct when re-
placing. (Check the label near the bulb.)
When replacing the lamp bulb, unplug the refrigera-
tor to prevent electric shock.
6cm 6cm
9cm
Adjustable feet
1.To ensure adequate ventilation for your refrigerator, it is
recommended to provide space of 6cm on both sides
and at the back, and space of 9cm above the refrigera-
tor. Insufficient spacing will decrease the cooling effi-
ciency, resulting in unnecessary consumption of elec-
tricity.
INSTALLATION
NOTE:
• Keep your refrigerator out of direct sunlight.
• Do not place next to heat generating appliance.
• Do not place directly on the ground. Provide suitable
stand.
2.Using the two front Adjustable feet, ensure that the re-
frigerator is positioned firmly and level on the floor.
&
&
%
!
"
#
$
%
'
%
!
"
#
$
%
'
!
"
#
%
$
6cm
113 cm
105 cm
