Front panel
Rear panel
FRONT PANEL AND BACK PANEL FUNCTION
60
POWER
VFD DISPLAY
IR SENSOR
DISC TRAY
DVD USB SWITCH
SEARCH
STOP
/
PLAY/ PAUSE
OPEN/CLOSE
AUDIO OUT LEFT 5 1 MODE
AUDIO OUT FRONT RIGHT 5 1 MODE
AUDIO OUT SUBWOOFER 5 1 MODE
YUV OUT PROGRESSIVE SCAN ENABLED
VIDEO OUT
VGA OUT
( .
)
( .
)
( .
)
(
)
USB
SCART
OPTICAL DIGITAL OUT
S VIDEO OUT
COAXIAL DIGITAL OUT
STEREO AUDIO OUTPUT RIGHT
STEREO AUDIO OUTPUT LEFT
AUDIO OUT CENTER 5 1 MODE
SURROUND AUDIO OUT RIGHT 5 1 MODE
SURROUND AUDIO OUT LEFT 5 1 MODE
POWER
-
( .
)
( .
)
( .
)
