6
Installation/Connection
Installation method 2: Installation
using the screw holes at the sides of
the unit.
Select a position where the screw holes of
the mounting bracket supplied with the car
and the screw holes of the main unit become
aligned (are fitted), and tighten the screws (see
at 2 places on each side). And then fasten
them to the car.
Car brackets
Dashboard
Detach the unit
1. Take out the outer trim ring.
2. Insert the keys supplied to the unit at both
sides of the unit (as illustrated) until they click.
Pulling the keys makes it possible to remove
the unit from the dashboard.
