40
5 Remove the SAFBAG dust bag module (18) from the
vacuum cleaner chamber.
6 Grab the dust bag cover, gently bend it towards the
inside and remove the whole dust bag upwards.
7 Insert the plate of the new dust bag in the tracks of the
SAFBAG dust bag module (18) and slide it until stop. The
direction for inserting the dust bag is indicated by the arrow
on the bag.
8 Slide the SAFBAG dust bag module together with the
installed bag in the tracks located on the side of the vacuum
cleaner chamber. Close the cover by pressing it until you
hear a characteristic click – pay attention not to trap the
dust bag.
ATTENTION! Do not vacuum without the SAFBAG dust
bag module installed in the appliance. The lack of the
SAFBAG dust bag module prevents from locking the
upper cover of the appliance.
ZELMER vacuum cleaners are equipped with SAFBAG dust
bags in the amount indicated in the table. It is recommended
to replace the dust bag if:
a) the dust bag full indicator lights up,
b) the vacuum cleaner operates poorly,
c) the dust bag is full.
Filter disassembly
Before changing the filters make sure that the vacuum
cleaner is switched off and unplugged from the mains
supply.
HEPA OUTLET FILTER
The vacuum cleaners are equipped with an H11 outlet filter
HEPA (High Efficiency Particulate Air). The HEPA filter has
been designed to maximize its filtration capability through
special fibers, which are able to retain almost all dust
particles. The H11 class determines the permeability of
a filter. The HEPA H11 filter retains 95,5% of particles of 0.3
micron.
1 To replace the HEPA filter lift the vacuum cleaner handle
and open the accessory compartment.
2 Grab the filter cover by the fastening, firmly pull with the
thumb and lift it upwards
3 Remove the HEPA filter case and replace it with a new
one. The HEPA filter ensures an effective operation of the
vacuum cleaner for about 1 year.
4 Insert the cover so that the two protrusions in the lower
part of the cover are inserted in the openings of the vacuum
cleaner body, press the filter cover so that the rear fastenings
snap shot on the body.
INLET FILTER
1 Release the upper cover fastening (12) and open the
cover.
2 Remove the SAFBAG dust bag module (18) from the
vacuum cleaner chamber.
3 Slide the inlet filter casing with the installed inlet filter
from the tracks on the back side of the vacuum cleaner
chamber.
4 Remove the inlet filter (16) from the inlet filter casing.
5 Place the new filter in the inlet filter casing (17) with the
material side directed towards the inside of the casing.
6 Slide the inlet filter casing (17) together with the filter in
the tracks until stop to the previous position.
ATTENTION! Always replace a damaged inlet filter (16)
with a brand new, original one.
7
Insert the SAFBAG dust bag module to the vacuum
cleaner chamber.
8 Close the cover by pressing it until you hear
a characteristic click – pay attention not to trap the dust bag.
Special accessories
The following special accessories may be purchased in retail
outlets:
Zelmer turbobrush (22)
May be used with all types of ZELMER vacuum cleaners. Is
used for an effective vacuuming of carpets and fitted carpets.
While using the turbobrush follow the instruction manual.
The use of the turbobrush decidedly increases the
effectiveness of removing fibrous dirt such as: animal hair,
hair, threads etc. It is practically useful in households with
pets (cats, dogs), where removing the animal hair from the
carpets and floorings is very onerous.
End of operation cleaning and
maintenance
1 Switch off the vacuum cleaner by pressing the “on/off”
button (7).
2 Unplug the appliance.
3 Wind the cord by pressing the cord rewind button (4).
While doing this hold the cord to make sure it is not tangled
and the plug does not hit the vacuum cleaner housing.
4 Disconnect the telescopic tube from the nozzle or brush.
5 Disconnect the telescopic tube from the hose.
6 Press the two side buttons on the end of the hose and
remove the hose end from the inlet opening of the vacuum
cleaner.
7 The vacuum cleaner may be stored vertically or horizontally.
In order to do so, insert the fastening hook of the combination
brush to the combination brush fastener. The hose may be
attached to the vacuum cleaner, however you have to make
sure that it is not excessively bent during storing.
8 If necessary wipe the housing and the dust bag container
with a damp cloth (it may be soaked with dishwashing liquid)
and dry it or wipe until dry.
Do not use abrasive detergents or solvents.
