VACUUM CLEANING
Before you start up your vacuum cleaner:
check if the bag is assembled inside the dust cup (1), air-inlet filter (2) and air
–outlet filter (3),
–
ATTENTION!!! Be careful during pulling the
cord out, the yellow mark on the cord shows
the end of the cord.
start the vacuum cleaner up pressing the(6)
– button and set appropriate suction
power.
SUCTION POWER REGULATION
The vacuum cleaner is equipped with electronic power regulation, which enables
fluent power regulation. Moving the cursor according to the symbols on the vacuum
cleaner results in increasing (+) or reducing (-) power.
The vacuum cleaner is also equipped with
mechanical suction power regulation on the
hose handle. It is enough to open the valve,
as it is shown in the drawing, to reduce the
suction power.
FULL DUSTBAG INDICATOR FUNCTION
When full dust bag indicator is covered (red colour), while the
nozzle or brush is elevated over the cleaning surface, it indi-
cates the necessity to remove or replace the bag. The full dust
bag indicator can operate in case of locking bar the hose or fit-
ted accessories. In such case:
Remove the hose end from the top lid and clean the hose
as well as the fitted accessories.
„PARKSYSTEM” FUNCTION – AUTO START
The vacuum cleaner is equipped with �Parksystem”
– “AUTO START” function: the function enables temporary
switching off the vacuum cleaner using the brush-nozzle
hook, without using on/off button. In order to do it, insert
the brush-nozzle hook into the casing socket (7) during
operation. The vacuum cleaner shall switch off automati-
cally.
SAFETY VALVE OPERATION
The vacuum cleaner is equipped with safety valve, (which is located inside the dust
compartment -bag). It opens automatically when the hose or fitted accessories are
blocked or the dust bag is excessively full of dust. You can hear characterstic �flutter-
ing” sound after valve opening.
–
–
ON/OFF
button
Suction power
adjustment knob
Cord rewind
button
SAFBAG dust bag
Gap nozzle Small nozzle Small brush BNB brush
Type 1500
ORION
Type 2500
COBRA II Silent / ORION MAX
Full bag indicator
insert one end of the flexible hose (4) into the air
intake duct, fit another end of the hose (handle)
with sucking tube,
fit the length of the telescope tube for desired
working position (depending on your size) press-
ing �A” button move the tubes in direction indi-
cated by the arrows,
fit the chosen accessories, i.e. brush-nozzle, in
another end of the tube,
pull the supplying cord(5) out of the casing and
insert the plug into power socket,
–
–
–
–
Turbo brush
Electro brush
