Connecting to the monitor output terminal ( t ), Connecting optional components (continued) – Инструкция по эксплуатации Sony wega KV-AZ212
Страница 8
Sony KV-AZ212M91 Group B25 (
GB
(dummy))_2-687-422-E2 (1)
DVD player
TV rear panel
Component video
cable
(not supplied)
Audio cable
(not supplied)
L
R
R
1
L
Y
C
B
C
R
(MONO)
(MONO)
Y
R
L
C
R
C
B
Connecting to the component video input terminal (
)
Notes
• If your DVD player can output interlace and progressive mode signals, select the interlace
output when connecting to
(component video input) on your TV. Your TV can receive
either 525i/60Hz or 625i/50Hz interlace signals.
• The component video terminals on your DVD player are sometimes labeled Y/C
B
/C
R,
Y/P
B
/
P
R,
Y/C
b
/C
r
or Y/B-Y/R-Y.
• If you select “DVD” on your TV screen, the signal from the T (monitor output) jacks will not
be output properly. This does not indicate a malfunction.
TV rear panel
Audio system
(
R
L
Y
C
B
C
R
MONO)
(
L
R
1
MONO)
R
L
VCR
Audio/Video
cable
(not supplied)
Connecting to the monitor output terminal ( T )
Connecting optional components (continued)
