Additional Information
Specifications
Model name KDL-40S40xx/40U40xx/
40L4000 KDL-40V4000/
40V42xx KDL-46V4000/
46V42xx KDL-52V4000/
52V42xx
System
Panel system LCD (Liquid Crystal Display) Panel
TV system Analogue: Depending on your country/area selection: B/G/H, D/K, L, I
Digital: DVB-T/DVB-C
Colour/video system Analogue: PAL, SECAM, NTSC 3.58, 4.43 (only video input)
Digital: MPEG-2 MP@ML/HL
Channel coverage Analogue: VHF: E2–E12/UHF: E21–E69/CATV: S1–S20/HYPER: S21–S41
D/K: R1–R12, R21–R69/L: F2–F10, B–Q, F21–F69/I: UHF B21–B69
Digital: VHF/UHF
Sound output 10 W + 10 W
Input/Output jacks
Aerial/cable 75 ohm external terminal for VHF/UHF
/ AV1 21-pin scart connector (CENELEC standard) including audio/video input, RGB input, and TV audio/
video output.
/ / AV2
(SmartLink)
21-pin scart connector (CENELEC standard) including audio/video input, RGB input, S video input,
selectable audio/video output, and SmartLink interface.
COMPONENT IN Supported formats: 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
Y: 1 Vp-p, 75 ohms, 0.3V negative sync/P
B /C B : 0.7 Vp-p, 75 ohms/
P R /C R : 0.7 Vp-p, 75 ohms
COMPONENT IN Audio input (phono jacks)
HDMI IN 1, 2, 3
(HDMI IN 3 is not available in
KDL-40L4000.)
Video: 1080/24p, 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
Audio: Two channel linear PCM: 32, 44.1 and 48 kHz, 16, 20 and 24 bits
Analogue audio input (minijack) (HDMI IN 2 only)
PC Input (see page 36)
AV3 Video input (phono jack)
AV3 Audio input (phono jacks)
DIGITAL AUDIO
(PCM) OUT (OPTICAL)
(except for KDL-40S40xx/
40U40xx/40L4000)
Digital optical jack
Audio output (phono jacks)
PC IN PC Input (D-sub 15-pin) (see page 36)
G: 0.7 Vp-p, 75 ohms, non Sync on Green/B: 0.7 Vp-p, 75 ohms/
R: 0.7 Vp-p, 75 ohms/HD: 1-5 Vp-p/VD: 1-5 Vp-p
PC audio input (minijack)
i Headphones jack
CAM (Conditional Access Module) slot
Power and others
Power requirements 220 V – 240 V AC, 50 Hz
Screen size (measured
diagonally) 40 inches (Approx. 101.6 cm) 40 inches (Approx.
101.6 cm) 46 inches (Approx.
116.8 cm) 52 inches (Approx.
132.2 cm)
Display resolution 1,920 dots (horizontal) × 1,080 lines (vertical)
Power
consumption in “Home”/
“Standard”
mode 175 W 175 W 215 W 222 W
in “Shop”/
“Vivid” mode 197 W 197 W 238 W 249 W
Standby power
consumption* 0.19 W
(Continued)
