ENGLISH
5
The Control Panel
1 Programme Guide
2 ON/OFF LAMP
It lights when the appliance is operating.
3 REDUCED SPIN BUTTON
Pressing this button the spinning speed is reduced from
700 to 400 rpm (model FLS 702) and from 800 to 400
rpm (model FLS 802).
4 Half load button
Pressing this button before starting the intense program
there will be one rinse less which leads to energy and
water saving.
5 TEMPERATURE SELECTOR
This control allows you to select the temperature of the
washing cycle in accordance with the kind of clothes to
be washed.
To select the required temperature turn the control until
the marker on the top coincides with the required
temperature (reference mark on the control panel).
On the program chart you will find the most appropriate
temperature for each kind of washing.
6 PROGRAM SELECTOR
To select the required program turn the control
clockwise until the marker on the top coincides with the
number of the required program (reference mark on the
control panel). If at any chance you pass by the required
number NEVER TURN THE CONTROL
ANTICLOCKWISE
just continue clockwise until the
required number is reached again.
1
3 2 4 6 5
40º- 60º
30º- 40º
40º- 60º
30º- 40º
2
3
1
2
40º- 60º
30º- 40º
60º- 90º
60º- 90º
4
5
6
1
1
1
8
9
7
10
FLS
1
2
13
7
6
3
4
5
8
9
10
11
12
30
°
40
°
50
° 60 °
70 °
80 °
90
°
