5
En
Eng
lish
The front cover is fastened to the enclosure at 4 points and can be removed if desired. To remove the cover, hold on to both
sides and slowly pull straight away from the speaker. To reattach, line up the 4 holes on the inner surface of the cover with the
4 corresponding pegs on the speaker and push gently.
■ Attaching fasteners to secure the front cover (NS-E9900)
Vibrations etc. incurred during use may loosen the front cover.
If the front cover falls off, it may cause personal injury and/or
damage the front cover and surrounding items.
To prevent the front cover falling off, attach the small fasteners
supplied to the front cover and to the speaker, as illustrated
right.
When using a banana plug (China model only)
1
Unscrew the terminal knob. Note that the cap
inside also comes off.
2
Remove the cap from the terminal knob.
3
Tighten the terminal knob.
4
Simply insert the banana plug into the terminal.
y Tip
To put the cap back in place, tighten the terminal knob first, and then fit the cap into the hole.
1
2
3
4
Banana plug
Terminal
REMOVING THE FRONT COVER
NS-E9900 NS-C9900
When the cover is removed, take care not to touch the speaker units with your hands or to exert excessive force
with tools.
• Wipe the surface of the speaker clean before attaching the fasteners. If the surface is dirty or wet, the adhesive
strength of the tape may weaken, and cause the front cover to fall off.
• Do not touch the glued surface after peeling off the seal from the fasteners. The adhesive strength of the tape
may weaken and cause the front cover to fall off.
• Make sure that the positions of the fasteners on the front cover match up exactly with those on the speaker.
