23
En
DISC OPERATION
Eng
lish
Sharpness Mid
Set this to adjust the sharpness of the image for the
intermediate frequencies.
Sharpness High
Set this to adjust the sharpness of the image for the high
frequencies.
DNR
Set this to reduce video noise.
Gamma
Set this to adjust the intensity of the picture non-linearly.
Chroma level
Set this to adjust the density of the color.
Chroma delay
Set this to adjust the advance delay of the chroma signal
for a perfectly clear picture.
True Life
Set this to adjust the intensity of the picture details. A
positive value enables you to reproduce the minute signals
of video sources. This function is only available for
progressive scan (using the component video jacks) and
HDMI output.
Availability of picture settings varies according to the
connection and settings.
All picture settings are not available for signals output from the
AV terminal.
You can enlarge the picture on the TV screen and to pan
through the enlarged picture.
1 During playback, press ZOOM repeatedly to
display the picture at different scales (ZOOM
150%, 200%, 300%, or 400%).
2 Press / / / to pan through the
enlarged picture.
3 Press ZOOM repeatedly to return to the original
size.
If the disc contains sequences recorded from different
camera angles, you can view the picture from a number of
different angles.
Viewing angles available for each disc may vary. Refer to the
operating instructions in the DVD menu or on its jacket.
Press ANGLE repeatedly to select the desired
angle.
HDMI
Progressive
(Component)
Interlaced
(Component/
S-video/
CVBS
(composite))
Brightness 0 to +6 0 to +6 0 to +6
Contrast –6 to +6 –6 to +6 –6 to +6
Hue –6 to +6 –6 to +6 –6 to +6
(S-video and
CVBS only)
Sharpness
Mid
Not
available
–6 to +6 –6 to +6
Sharpness
High
Not
available
–6 to +6 –6 to +6
DNR 0 to +6 0 to +6 0 to +6
Gamma Not
available
–6 to +6 –6 to +6
Chroma
level
–6 to +6 –6 to +6 –6 to +6
Chroma
delay
Not
available
–2 to +2 –2 to +2
True Life 0 to +6 0 to +6 Not available
Note
Zooming pictures
(DVD-Video/VCD/SVCD/DivX
® /
JPEG)
Viewing angles (DVD-Video)
Note
SUBTITLE AUDIO ZOOM ANGLE
ON SCREEN TOP MENU
MENU RETURN
ENTER
ZOOM
/ / /
SUBTITLE AUDIO ZOOM ANGLE
ANGLE
