ASSEMBLY AND USE
5. The Round Brush and the Curved Nozzle Accessory can be attached to end of the Jet
Nozzle by pushing the accessory on using the hexagonal alignment as a guide.
Nylon Round Brush
Round Brush recommended for cook tops and bench
tops.
Angled Nozzle
Curved Nozzle recommended for hard reaching area
such as window sills and toilet
To use the Window Cleaning attachment It must be
clipped Into the Fabric Accessory by hooking the
two hinges onto the tabs and lifting the window
cleaner around to the top of the fabric tool and
clipping the latch onto the fabric cleaner to secure
In place. To remove the window cleaner, simply lift
the latch to uncllp and separate.
WARNING: Using window cieaner on cold
glass may cause the glass to break. Proceed
with caution when carrying out this operation.
To use the Fabric Accessory, stretch the Cloth
Covering to fit over the Fabric Accessory. It Is
recommended that the Fabric Accessory be
attached to the flexible hose for maximum
accessibility for clothing, upholstery and window
furnishings.
STARTING THE STEAM CLEANER
8. PlugthepowercordIntoanelectrIcaloutlet.ResIstanceIndIcatorllghtgoeson.
9. After 3-4 minutes the appliance Is ready to generate the steam.
WARNING: Do not leave the steam cleaner unattended while waiting for steam.
10. Press the Steam Lever to emit the steam and begin passing slowly over the surfaces
Intended for cleaning. For disinfecting areas, hold the steam cleaner no more than 1
Inch away from the surface and pass over slowly until entire area Is covered.
FURTHERWATERTANK FILLING
11. Unplug the power cord from electrical outlet.
12. Press and hold Steam Lever until all pressure has been released.
13. Before opening Water Tank Cap It Is Importantto wait approximately 3 minutes for the
P/5
appliance to cool down. Slowly turn the cap, only a half turn, and wait for the hissing
sound (If any) to completely stop. The hissing sound may be present due to residual
pressure not released while holding the steam lever.
14. Carefully press the cap and unscrew It and follow process outlined In step 1 and 2.
MAINTENANCE
NOTE: Please ensure the steam cleaner has been unplugged from the power source and
cooled down before any cleaning and maintenance Is carried out.
15. Always empty any excess water from water tank after each use. This operation will
prolong the life of your appliance.
16. Always ensure the unit has cooled before putting it away in a dry, cool place.
17. To ensure the highest level of operation over a long period of time, It Is recommended
that the water tank be rinsed out with water at least once a month to clean any water
calcification accumulated. Do not use vinegar or other substances to remove lime
scale deposits.
18. To clean fill with one measure of water, replace cap and shake unit to loosen any lime
scale deposits. Remove cap and empty waterfrom tank.
WARNING: Do not Immerse the steam cleaner In water.
TECHNICAL SPECIFICATIONS
Voltage: 220-240 V-50 Hz
Power: 1200 Watt
TROUBLE
PROBLEM
Unit will not srt'iTh on.
Unil Djl ïHïiter frmn nozzle.
SHOOTING GUIDE
POSSIBLE SOLUTION
EiBure the powe- cord has seen plugged 1п’л
s. power bocliel and Cts cjtlsl is s'^tch ON.
Chenk Ihs л'яге'lank islili'id cn fneerly Try
anclhsr power oudet.
Level in water tar^k may be teo hign. Check
wrater tank and do ao: oveftill так 4QC-ml. Hold
In upr^ht positlan. Do not tjm ;he steame' nn
hs side. Unit not to iy heated. Allow the unit
time 1c heat the water
Accessc'ies. once attached do net stay on.
Unit is not pnoduc np steam.
Check that enough foiice has been applied to
ensure tne aocessories sne sfl<?jnad. Read
over accessory inEtallaton steps.
Ensure that the v.ratertanA has oeen filled with
the correct l^el of water. Ensure the unit .s
pugged inlc a pa'*ierouter. P'ass Steam
Lever. Ensure there is nc tJockags
clranging accssscry._____________________
IMPORTANT
Electrical Requirements:
Please ensure that the voltage shown on the rating plate of your appliance coTesponds with
your household electricity supply which must be A.C. (alternating current).
p/6
