Operating the Grill (it available^:
Turn the oven and grill control knob by pressing and rotating in to the grill
position.
for the models without ignition;
While the knob is pressed position, ignite the burner by lighter or a
match and wait to ignite,
for the models with electrical ignition;
While the knob is in pressed position, press the ignition button.
After the gas in the grill burner is ignited, keep the knob in the pressed
position for 5-10 seconds. After you release the knob, if the ignition does
not continue repeat the same process by keeping the knob pressed for
15 seconds. If still no igniton occurs, wait for 1 minute and repeat again
Warning: Do not keep the knob in pressed position more
than 15 seconds.
«•" After ignition close the door perform a 10 minutes
preheating.
Apply oil on the grill shelf to prevent
sticking on the bars.
Locate the grill shelf to the 3 or 5th shelf on the oven.
Locate a tray to one of the bottom shelves in order to
collect to oils and for easy cleaning put some water in it.
Using the Knob Heat Shield housing
into Oven Door (for suitable models)
WARNING! Do not grill when the front
door is closed. Otherwise, oven parts
may be damaged. After preheating, keep
the front door half-open during grilling.
In order to prevent the knobs of the control
panel from heating up, center the knob
shield plate between the front cover and
the oven housing without leaving any
gap.
Using the Knob Heat Shield housing into Oven Body (for suitable models)
WARNING I: After preheating, keep
the front door fully open during grilling.
In order to prevent the knobs of the
control panel from heating up, the knob
heat shield plate must be placed in the
housing where the bottom of the control
panel shown in the figure.
Control panel
WARNING !: After preheating, keep
the front door fully open during grilling.
In order to prevent the knobs of the
control panel from heating up, the knob
heat shield plate must be placed in the
pins at the bottom of the control panel
shown in the figure.
Knob beat shield \ Front door Knob heat shield
-f3
