SoundMax SM-CDM1033 - Инструкция (Страница 19)

19
Specification
Specifications are subject to change without notice. Mass and dimension are approximate.
General
Power supply
12 V DC
Current consumption max. 9.5 A
Maximum power output 50 W x 4 channels
Fuse 10 A
Dimensions (L x W x H) 178 x 165 x 50 mm
FM stereo radio
Frequency range
87.5 - 108.0 MHz
Usable sensitivity 3 uV
MW Section
Frequency range
522 kHz-1620 kHz
Usable sensitivity 32 dB
Disc player
System:
Compact disc audio system
Usable disc: MP3/ CD-R/ CD-RW
Frequency characteristics: 20 Hz - 20 kHz ± 5 dB
Signal to noise CD: 60 dB
Number of channels: 2 stereo
Line out
Output:
CD max 1000 mV
