1
(Pfif^) > mmmmmm^mm
mm^
mmMm
VIDEO OUT
AUDIO OUT
/ mim Aimi)
VIDEO IN (f^lt)
AUDIO IN (^?i)
2
mmmo
3 ^
[VCR/CAMERA]
M
’
MM
[VCR]
°
• [vcR]i^;TT:TtO:^ie °
4
(->62)
^^^S^RF«S^(VW-RF7r - iSHiliiM)
Watching Playback on a TV Set
By connecting the Movie Camera to a TV, you can watch
playback of the recorded scenes on the TV screen.
Before connecting, turn off both the Movie Camera and
the TV for safetyis sake.
1
Use the AV Cable (supplied) to connect the
Movie Camera with the TV.
Movie Camera
TV (AV Input Sockets)
VIDEO OUT
—^ VIDEO IN
AUDIO OUT
------> AUDIO IN
2
Select the channel on the TV which
corresponds to the video/audio input
sockets used for connecting.
(Refer to the operating instructions of your TV).
3
Press the [VCR/CAMERA] Button to select
the VCR Mode.
•The [VCR] Lamp O lights.
4
start playback on the Movie Camera. (-> 62)
if your TV is not equipped with AV Input Sockets, the RF
Adaptor (VW-RF7E; optional) is necessary.
Consult your dealer.
64
