1 mmm/mimmiim),
m^mmo
mmmi^mm/mimxmi)
[ V I D E O O U T ] ^ V I D E O
[ A U D I O O U T ] > A U D I O I N ( ^ M )
i^mm.mmmo
3
®
[VCR/ CAMERAjli, ^iS[VCRj;i:*;Igo
• [VCRUgTFitO^iS.,
#RFlli^^(VW-RF7E,
,,
Playing Back on a TV
By connecting the Movie Camera to a TV, you can
watch playback of the recorded scenes on the TV
screen.
Before connecting, turn off both the Movie Camera and
the TV for safety's sake.
1 Use the AV Cable (supplied) to connect
the Movie Camera with the TV.
Movie Camera
TV (AV Input Sockets)
[VIDEO OUT]
VIDEO IN
[AUDIO OUT] --------------> AUDIO IN
2
Select the channel on the TV which
corresponds to the video/audio input
sockets used for connecting.
(Refer to the operating instructions of your TV)
3
Press the [VCR/CAMERA] Button to
select the VCR Mode.
•The [VCR] Lamp O lights.
4
Start playback on the Movie Camera.
(->56)
• If your TV is not equipped with AV Input Sockets, the
RF Adaptor {VW-RF7E: optional) is necessary.
Consult your dealer.
58
