1
iStic iB/'^SÌ °
Charging the Battery
1
2
A : fllPgÌ5$S^°
• aSÌR/Tx® [POWER]©.I5ÌB .
[CHARGE lOferaOnrOìS ■ fjrlÌifì^B -
• ACIREPiÌBS^S/«CtS ' J
e
SÌI
h
A^S
ì
CHARGE]©te
tetete
’ ìÌ0GPiteTm>tì ' StesISSI-CC “
Attach the Battery.
• Align the Battery with line Q and push it in the
direction of the arrow while holding it down.
Securely connect the AC Mains Cable to
the AC Adaptor and an AC Mains Socket.
(
a
): Hong Kong only
•The [POWER] Lamp
Q
lights and then the
[CHARGE] Lamp © flashes and charging starts.
• If the [CHARGE] Lamp @ does not flash even
though the Battery is attached, remove the Battery
and then re-attach it.
Charging Lamp [CHARGE]
■
[ C H A R G E ]
30^"'if ° )
Flashing
Lit:
^ /C hh- ^
a
F:. W.'
mmtamy&m
During charging
The Battery can already be used to
operate the Movie Camera but is not yet
fully charged. (Approx. 30-minute battery
charge)
The Battery is fully charged.
■ Removing the Battery
Slide it in the opposite direction of that indicated in step 1
above.
Off
•
10“C-30'C ^
•
’ ?cmii/i3^i[CHARGE
ì
Qm^diAwm-T ’
~j A ^
• Charge the Battery at a room temperature
between 10"'C and 30°C.
•When charging, do not connect the DC Input
Cable to the AC Adaptor.
• If you charge the Battery when it is not yet
discharged, the [CHARGE] Lamp © may flash
briefly and then go out. This indicates that the
Battery is fully charged.Therefore, this is not an
indication of a malfunction.
• During recording or charging, the Battery
becomes warm. However, this is normal.
18
