Sc
=mmm
• (-»18)
2. «jftdifl«:)
«" (-»18)
• €Sia>nm±®ffla0i^« •
[DClNlJaîL"
(DC OUT] ffiîL»
3
ÈS^55>iîiMggsA« Êifijsffl
scm 00-240V.
50/60HZ) -
mm-
ENGLISH
The 3 Types of Power Supplies
To try out the Movie Camera at home, we recommend
that you use the AC Adaptor O.
1. AC Adaptor (supplied)
•To use the Movie Camera indoors.
•To charge the Battery. (•♦ 18)
2. Battery (supplied)
•To usé the Movie Camera outdoors, and also indoors
when there is no AC mains socket nearby. (^ 18)
3. Car Battery Charger (optional)
•To use the Movie Camera in a car.
Using the AC Adaptor as Power Supply
Unit
1
Connect the DC Input Cable to the
[DC IN] Socket on the Movie Camera.
Connect the other end of the cable to the
[DC OUT] Socket on the AC Adaptor.
Connect the AC Mains Cable to the AC
Adaptor and to an AC mains socket.
2
3
The AC Adaptor features automatic universal voltage
adjustment (AC 100-240 V, 50/60 Hz), therefore, there is
no need for any manual voltage adjustment for use in
other countries.
16
