CAUTION:
Ensure that none of the system air vents are blocked. Blocking them
would cause serious thermal problems.
Back Panel Connectors
3
power connector
Insert the power cable.
4
voltage selector
switch
For selecting voltage rating.
5
back panel
connectors
Plug USB, audio, and other devices into the appropriate
connector (see "Back Panel Connectors" on page 31 for
more information.
6
card slots
Access connectors for any installed PCI and PCI Express cards.
1
parallel
connector
Connect a parallel device, such as a printer, to the parallel
connector. If you have a USB printer, plug it into a USB
connector.
NOTE:
The integrated parallel connector is automatically
disabled if the computer detects an installed card containing a
parallel connector configured to the same address. For more
information, see "System Setup Options" in the online User’s
Guide.
1
3
9
8
7
5
6
2
4
