17
GB
ț Never vacuum liquids or carry out spray extraction
without the soiled-water tank.
ț Your THOMAS TWIN is not suitable for extracting large quantities
of liquids from tanks or basins.
Prior to wet-cleaning carpets
ț
Before wet-cleaning carpets, the entire area to be cleaned is to be
thoroughly vacuumed.
Do not wet-clean delicate, hand-woven or non-
colourfast carpets.
For test purposes, apply a little detergent solution to a white cloth
and rub a concealed area of the carpet with this cloth. If there are
no traces of colour on the cloth, it may be assumed that the carpet
is colourfast. Should colour rub off onto the cloth, the carpet must
not be wet-cleaned.
Should you be unsure, consult a carpet dealer.
If the carpet has been shampooed at an earlier juncture, this may
result in considerable foaming in the soiled-water tank when the
THOMAS TWIN is used for the first time. To prevent further foaming,
pour
1 /
2
a cup of vinegar into the soiled-water container.
Should foam emerge from the air outlet, switch the appliance off
immediately and empty the soiled-water tank.
Strong foaming is no longer possible after cleaning once with
THOMAS ProTex cleaning concentrate, as this agent contains a
special foam inhibitor.
Do not walk on the carpet as long as it remains damp.
The room should be well ventilated during and after cleaning, to
enable swift drying.
ț Caution! Never run the pump without liquid.
ț Please also observe the "Important information" in
Section 1 .2
5.2 Set-up wash-vacuuming
General proparation
H Open the casing cover (1) by lifting the cover release (4).
F Put together the 2-part anti-slosh insert (22)
G Lift the AQUA filter (42) out of the dirty-water container (24) by
its handle and insert the anti-slosh insert (22).
I Remove the HEPA filter (20) from the appliance.
J Insert the anti-slosh insert (22) and dirty-water container (24)
into the appliance. Ensure that the wet filter (23) and the motor
protection filter (21, illus. I) are in place.
Fold the carrying strap away to the side so that it does not cover
the casing seal.
G Ensure that the float (59) in the dirty-water container (24) is kept
clean and in good condition. It automatically interrupts the suction
when the dirty-water container is full.
K Remove the fresh water tank for filling (draw tank straight upwards
and out of the cleaner or fill up directly in the appliance. In this
case you have to lift up fresh water tank cover.
When filling make sure that no impurities get into the fresh water
tankto prevent the dosing valve from not functioning properly.
Fill up with cleaning concentrate and water to the grip lug (max.
2,4 litres).
We recommend the THOMAS ProTex original
concentrated cleaning agent for cleaning carpets.
See label on the cleaning concentrate bottle for application and
dosage.
Use hand warm water (max. 30°C).
Close the flap (5) and replace the fresh-water tank (6).
L Slide the cut-out valve (25) into position on the suction pipe (34).
Secure the cleaning agent hose (26) on the suction hose (28) using
4 plastic fasteners (33).
B Press the detergent hose (26) firmly into the quick-release coupling
(8) until it snaps into place.
To release, press the button on the quick-action coupling (8).
N Take the suitable nozzle and assemble it according to the
illutration
– Carpet-spray-extraction-nozzle (30) incl. hard floor aadaptor
(31) for cleaning of hard floors and tiles
– Carpet-spray-extraction-nozzle (30) for cleaning of carpet
floors
M Put the detergent hose (32) with the quick-release coupling (64) on
the shut-off valve (25) and rotate until it is locked. Afterwards, the
detergent hose (32) fasten the detergent hose to the suction tubes
(34) using the 2 smaller plastic clips (40).
K Pull the mains plug (63) out of the appliance and connect it.
Window cleaning
Push the window nozzle adapter on the carpet spray nozzle.
With this system you can clean and dry your window and glass surfaces
at the same time.
See procedure as for carpet cleaning.
Absaugen und
Aufrichten
Arbeitsrichtung
Einsprühen
Saugr
ohr
Druckleitung
Lösen und Auswaschen
The spray extraction system
ț The cleaning solution is sprayed deep into the
carpet under pressure
ț Dirt is detached and washed out fibre-deep
ț Soiled water is extracted at maximum power and carpet
pile restored to upright position.
All in one operation.
Suction tube
Detachment and washing out
Spraying
Extraction and
restoration to
upright position
Pressur
e pi
pe
Working direction
1.
2.
A
B
clic
k
1 2
A
J
H H
click
1.
2.
3. 4.
5.
B
H H
3 3a
3b
ȦȨ 3a
ȦȨ 3b
