Radius and capacity / Portée et charge / Sbraccio e portata
Alcances y cargas / Alcance e capacidade de carga /
Вылет и грузоподъемность
Ausladung und Tragfähigkeit
HC-L
35
7
Tragfähigkeiten gültig bis 100 m Hubhöhe. Über 100 m Hubhöhe reduziert sich die Tragfähigkeit um das zusätzliche Seilgewicht. / Lifting
capacities valid up to 100 m hoisting height. Over 100 m hoisting height, the lifting capacity is reduced by the additional rope weight. / Capacités
de levage valables jusqu’à 100 m de hauteur sous crochet. Au-dessus de 100 m de hauteur sous crochet, la capacité de levage est réduite du
poids de câble supplémentaire. / Portate valide fino a 100 d’altezze di sollevamento. Oltre i 100 m si riduce la portata causa il peso addizionale
della fune. / Cargas válidas hasta altura de 100 m. Por encima de los 100 m se reduce la carga por el peso adicional del cable. / Cargas válidas
ate ã altura de 100 m. Para alem dos 100 m, reduz-se a carga pelo peso adicional do cabo. /
Грузоподъемность действительна до 100 м высоты
подъема. Свыше 100 м высоты подъема грузоподъемность сокращается на вес дополнительного каната.
Minimum Ausladung außer Betrieb / Minimum radius out of operation / Portée minimum hors service / Sbraccio minimo fuori servizio
Alcance mínimo fuera de servicio / Alcance mínimo fora de operação /
Минимальный вылет вне работы
m
m/kg
m/kg
20,0
22,5
25,0
27,5
30,0
32,5
35,0
37,5
40,0
42,5
45,0
47,5
50,0
52,5
55,0
57,5
60,0
60,0 (18,5)
4,0 – 35,2
12000
12000 12000 12000 12000 12000 12000 12000 11040 10070 9200
8380
7630
6930
6270
5650
5070
4500
4,0 – 18,0
24000
21710 19280 17220 15440 13870 12480 11230 10100 9070
8120
7240
6430
5680
4970
4300
59,4 m
3200
55,0 (18,0)
4,0 – 37,6
12000
12000 12000 12000 12000 12000 12000 12000 12000 10920 9870
8940
8060
7230
6450
5700
4,0 – 19,5
24000
23360 20630 18320 16340 14620 13100 11760 10540 9440
8440
7520
6670
5880
54,4 m
4600
50,0 (17,4)
4,0 – 39,8
12000
12000 12000 12000 12000 12000 12000 12000 12000 11900 10680 9560
8510
7500
4,0 – 21,0
24000
24000 22240 19690 17510 15610 13930 12440 11100 9880
8770
7740
49,4 m
6100
45,0 (16,7)
4,0 – 42,0
12000
12000 12000 12000 12000 12000 12000 12000 12000 12000 11630 9800
4,0 – 22,5
24000
24000 24000 21170 18740 16630 14770 13110 11620 10250
44,4 m
8100
40,0 (15,7)
4,0 – 40,0
12000
12000 12000 12000 12000 12000 12000 12000 12000 12000
4,0 – 23,4
24000
24000 24000 22120 19530 17270 15270 13490
39,4 m
10700
35,0 (14,6)
4,0 – 35,0
12000
12000 12000 12000 12000 12000 12000 12000
4,0 – 23,7
24000
24000 24000 22470 19830 17520
34,4 m
14000
30,0 (15,1)
4,0 – 30,0
12000
12000 12000 12000 12000 12000
4,0 – 24,0
24000
24000 24000 22790
29,4 m
18100
