LCD display
1
9
2
4 5 6 7 8
3
1 Main display section
Shows the various information such as
band, play time, and other setting.
! Tuner
Band and frequency are displayed.
! Built-in CD Player (Audio CD)
Erapsed play time is displayed.
! Built-in CD Player (WMA/MP3/WAV disc)
Folder number and erapsed play time are
displayed.
! Audio and initial setup
Function names and setup status are dis-
played.
2 Stereo (5) indicator
Shows when the selected frequency is
being broadcast in stereo.
3 Preset number/track number indicator
Shows the track number or preset number.
! If a track number 100 to 199 is selected,
d on the left of the track number indica-
tor will light.
! If a track number 200 or more is selected,
d on the left of the track number indica-
tor will blink.
4 LOUD indicator
Appears in the display when loudness is
turned on.
5 LOC indicator
Shows when local seek tuning is on.
6 RPT indicator
Shows when repeat play is turned on.
7 FIE indicator
Shows when the front image enhancer is
turned on.
8 MP3/WMA indicator
Shows the type of the currently playing disc.
9 CUSTOM indicator
Shows when custom equalizer curve is cur-
rently selected.
Basic Operations
Turning the unit on and
selecting a source
You can select a source you want to listen to.
To switch to the built-in CD player, load a disc
in the unit (refer to the next page).
% Press SOURCE to select a source.
Press
SOURCE repeatedly to switch between
the following sources:
Built-in CD player
—Tuner
Notes
! When no disc has been set in the unit, the
source will not switch to the built-in CD player.
! When this unit’s blue/white lead is connected
to the vehicle
’s auto-antenna relay control
terminal, the vehicle
’s antenna extends when
this unit
’s source is turned on. To retract the
antenna, turn the source off.
Adjusting the volume
% Use VOLUME to adjust the sound level.
Operating this unit
