8
FUNCTION OVERVIEW
SUBWOOFER FRONT PANEL CONTROLS AND INDICATORS
indicator Indicates the unit is on or in standby mode
indicator Indicates DVD 5.1 channels signal input selection
Indicates AUX Stereo signal selection
Indicates 2.1 sound field selection
Indicates 5.1 sound field selection
Indicates main volume decreasing
Infrared sensor for receiving remote control signals
button Press this button to decrease main volume
button Press this button to select DVD or AUX signal input
+ Indicates main volume increasing
STANDBY
DVD
AUX
2.1
5.1
VOLUME-
IR
VOLUME-
DVD/AUX
indicator input
indicator
indicator
indicator
indicator
indicator
+ button Press this button to increase main volume
button Press this button to select 2.1 or 5.1 sound field
button Press this button to turn On/Off the unit or set it
in standby mode
VOLUME
VOLUME
2.1/5.1
STANDBY
5.1 ACTIVE SOUND SYSTEM HXS 532
