INSTALLATIONS
Front right
Surround left
R
L
CD; TAPE DECK
DVD
F.L.
F.R.
CEN.
SW.
S.L.
S.R.
Center
Surround right
Front left
7
m
m
1
2
3
CONNECTING COMPONENTS
Connection
method of
binding clip:
Open the
lock bar
Insert the
loudspeaker
wire
Release the
lock bar
STEREO OUPUT
5.1 OUPUT
CAUTION:
If the loudspeakers you want to
are not
please connect the
with
as
i
SPECIFICATIONS of the user’s manual
Make sure there are not short-circuits on the speaker cable and the speaker terminals,
otherwise, it may damage the amplifier.
connect
the supplied ones,
speakers
the same speaker impedance (SPEAKER IMPEDANCE)
indicated n
the
.
DO NOT connect more than one speaker to one speaker terminal.
Care must be taken in selecting a location for speaker installation on a wall. Injury to
personnel or damage to equipment may result if the speakers installed interfere with
daily activities.
