Front panel
1. Standby indicator
6. Mode indicators
2. Standby button 7. Mode button
3. IR window 8. Volume indicators
4. Mute indicator 9. Volume buttons
5. Mute button
6. SPECIFICATION
Notes:
1. Given specifications may not serve the basis for claims.
2. Sven production is constantly developed. That’s why the specifications may be changed without preliminary notice.
Eng SVEN HT 425
Standby
Mute
Front Mode
Level
Up
Down
Woofer
Center
Right
Max
3
2
1
Min
Standby
Mute
Front Mode
Level
Up
Down
Woofer
Center
Right
Max
3
2
1
Min
R
1
2
3
5
7
9
4
6
8
1
2
3
7
6
10
9
4
5
8
15
Remote control
1. Standby button
2. Mute button
3. Master volume control buttons
4. Subwoofer volume control buttons
5. Front volume control buttons
6. Center volume control buttons
7. Rear volume control buttons
8. Tremble tone control buttons
9. Middle range tone control buttons
10. Bass tone control buttons
Output power (RMS):
subwoofer
woofer 30 W
5 х 15 W
Speaker unit:
subwoofer
woofer 5.25"
2 x 2.5" (full range) and 2" (tweeter)
Frequency response
subwoofer
woofer 40 –180 Hz
100 – 20 000 Hz
Power supply 220 V AC, 50 Hz
Dimension:
subwoofer
woofer L 200 x D 320 x H 318 mm
L 80 x D 225 x H 80 mm
Weight 11.8 kg
