5. INSTALLATION AND OPERATION GUIDE
1. Connect the subwoofer and the front, center, surround speakers with link cables.
2. Insert one end of the signal input cable into the output port of audio (video) player (DVD, CD/VCD, TV, TAPE), then connect anoth
er end with input port at the back of the subwoofer.
3. Plug into power connector for power and press power ON/OFF button.
4. Select the sound input mode. Select «5.1», the six speakers are on playing despite AC 3 input, select «TV/AUX», only the front
speakers are on work.
5. Adjust the F.VOL buttons (on front panel or remote consol) on for your satisfied front speaker volume effect.
6. Adjust the S.VOL buttons for your satisfied surround effect.
7. Adjust the C.VOL buttons for your ideal center effect.
8. Adjust tone control buttons for your satisfied tone effect.
Connection guide
1. AC 3 input
2. 5.1/TV/ AUX input mode slide switch
3. TV input
4. AUX input
5. Power cable
6. Power ON/OFF
7. AC 3 output
Eng SVEN HT 425
13
Center speaker
Left rear
speaker
Left front
speaker
Right rear
speaker
Right front
speaker
Subwoofer
