GB

TECHNICAL DATA

Oven dimensions
(WxDxH)

38x34x39 cm

Volume

50 l

Useful
measurements
relating to the oven
compartment

width 42 cm
depth 44 cm
height 18 cm

Power supply
voltage and
frequency

see data plate

Electric hob
Front left
Back left
Back right
Front right
Maximum absorption
of the electric hob

600 W

2000 W
1500 W

1500 W


5600 W

ENERGY LABEL

Directive 2002/40/EC on the
label of electric ovens. Standard
EN 50304

Declared energy consumption
for Natural convection Class –
heating mode:

a

Static

EC Directives: 2006/95/EC
dated 12/12/06 (Low Voltage)
and subsequent amendments -
2004/108/EC dated 15/12/04
(Electromagnetic Compatibility)
and subsequent amendments -
93/68/EEC dated 22/07/93 and
subsequent amendments -
2002/96/EC.
1275/2008 (Stand-by/ Off mode)

6. Close the terminal board cover by tightening the
screws V.

Connecting the supply cable to the mains

Install a standardised plug corresponding to the
load indicated on the data plate located on the
appliance.
The appliance must be directly connected to the
mains using an omnipolar circuit-breaker with a
minimum contact opening of 3 mm installed between
the appliance and the mains. The circuit-breaker
must be suitable for the charge indicated and must
comply with current electrical regulations (the
earthing wire must not be interrupted by the circuit-
breaker). The supply cable must be positioned so
that it does not come into contact with temperatures
higher than 50°C at any point.

Before connecting the appliance to the power
supply, make sure that:
• The appliance is earthed and the plug is compliant

with the law.

• The socket can withstand the maximum power of

the appliance, which is indicated by the data
plate.

• The voltage is in the range between the values

indicated on the data plate.

• The socket is compatible with the plug of the

appliance. If the socket is incompatible with the
plug, ask an authorised technician to replace it.
Do not use extension cords or multiple sockets.

! Once the appliance has been installed, the power
supply cable and the electrical socket must be
easily accessible.

! The cable must not be bent or compressed.

! The cable must be checked regularly and replaced
by authorised technicians only.

! The manufacturer declines any liability should
these safety measures not be observed.

*

Only available in certain models.

Data plate, is located inside the flap or, after the
ovencompartment has been opened, on the left-hand
wall inside the oven.

16
