38

English

Setup

Network

To begin setting up the network connection for
your product, follow these steps:

In the Home menu, press the ◄► buttons to
select the Settings, and then press the
ENTER button.

Press the ▲▼ buttons to select Network,
and then press the ENTER button.

Press the ▲▼ buttons to select Network
Settings, and then press the ENTER button.

Press the ▲▼ buttons to select Network
Type, and then press the ENTER button.

Press the ▲▼ buttons to select Wired or
Wireless, and then press the ENTER button.

Go to the next section.

Network Settings

Please contact your ISP to fi nd out if your IP
address is static or dynamic. If it is dynamic, we
recommend using the Auto setting. This is the
easiest and will work in the majority of cases. If it is
static, you must use the manual set up procedure.

Directions for wired networks are below. Directions
for wireless networks are after the directions for
wired networks.

Wired Network

In the Network Settings menu, press the
▲▼ buttons to select Network Setting, and
then press the ENTER button.
The Internet Protocol Setup screen appears.

Press the ► button, then select Auto or
Manual, and then press the ENTER button.

Setting Up a Wired Connecton - Auto

If you selected Auto, the Network Function
acquires and fi lls in the values for IP Address,
Subnet Mask, etc., automatically.

NOTE

This process can take up to fi ve minutes.

1.

2.

3.

4.

5.

6.

1.

2.

1.

Display

Audio

System

Network

Language

Security

General

Support

Settings

On-Screen Menu

:

Disc Menu

:

Audio :

Subtitle :

Network Setting

Internet Protocol Setup : Auto

\

IP Address

: 0 0 0 0

Subnet Mask

: 0 0 0 0

Gateway :

0 0 0 0

DNS

:

Auto

DNS Server

: 0 0 0 0

> Move

" Select ' Return

After the Network Function has acquired the
network values, press the RETURN button.
Then, run a Network Test to ensure the
product has connected to your network (See
page 41).

If the Network Function does not acquire the
network values or you selected Manual, go to
the directions for Manual Setup.

Setting Up a Wired Connecton - Manual

If the Auto Setting does not work, you’ll need to set
the Network Setting values manually.

To get the Network setting values from most
Windows computers, follow these steps:

Right click the Network icon on the bottom
right of the screen.

In the pop-up menu, click Status.

On the dialog that appears, click the Support
tab.

On the Support tab, click the Details button.
The Network settings are displayed.

To enter the Network settings into your product,
follow these steps:

On the Internet Protocol Setup screen, press
the ENTER button.

Press the ▲▼ buttons to select Manual,
and then press the ENTER button.

Press the ▼ button to go to the fi rst entry
fi eld (IP Address).

2.

3.

1.

2.

3.

4.

1.

2.

3.
