► Type B Model
Left View
1
Security Lock Port
You can connect a Kensington lock to the Security Lock Port to
prevent the computer from being stolen.
2
DC Jack
A jack to connect the AC adapter that supplies power to the
computer.
3
Monitor Port
A port used to connect a monitor, TV or projector supporting a
15pin D-SUB interface.
4
Wired LAN Port Connect the Ethernet cable to this port.
5
Digital Video/Audio Port
(HDMI) (Optional)
You can connect an HDMI cable to this port. Using this port, you
can enjoy digital video and audio on the TV.
6
eSATA/USB Common
Port (Optional)
This port can be used to connect a USB or eSATA device.
Windows XP does not support eSata.
7
Chargeable USB
Port (Optional)
You can connect USB devices to the USB port such as a
keyboard/mouse, digital camera, etc. (Chargeable USB: You
can charge USB devices through the USB port even when the
computer is turned off.)
 Charging a device through a Chargeable USB
takes longer than using a regular charger.
 Press the F2 key when the Samsung logo
appears in the booting sequence to enter the
BIOS Setup, select Advanced > USB Charge In
Sleep Mode, and set it to Enable. Then you can
use the Chargeable USB Port feature even in
sleep mode.
8
Microphone Jack A jack used to connect the microphone.
9
Headphone Jack A jack used to connect the headphones.
10 ExpressCard Slot
(Optional)
Install the Express card into this slot.
2 1 3 4 5 6 8 9 7 10
