1-34
Left View
Either type A or B is provided depending on the model.
► Type A Model
2 1 3 4 5 6 7 8
1
Security Lock Port
You can connect a Kensington lock to the Security Lock Port to
prevent the computer from being stolen.
2
DC Jack
A jack to connect the AC adapter that supplies power to the
computer.
3
Monitor Port
A port used to connect a monitor, TV or projector supporting a 15pin
D-SUB interface.
4
Wired LAN Port Connect the Ethernet cable to this port.
5
Digital Video/Audio Port
(HDMI) (Optional)
You can connect an HDMI cable to this port.
Using this port, you can enjoy digital video and audio on the TV.
6
USB Port or
Chargeable USB
Port (Optional)
A USB port or chargeable USB port is provided.
The port can be distinguished by the figure (
or
) printed on the port of the product. printed on the port of the product.
You can connect USB devices to the USB port such as a keyboard/
mouse, digital camera, etc. (Chargeable USB: You can charge USB
devices through the USB port even when the computer is turned off.)
 Charging a device through a Chargeable USB
takes longer than using a regular charger.
 Press the F2 key when the Samsung logo appears
in the booting sequence to enter the BIOS Setup,
select Advanced > USB Charge In Sleep Mode,
and set it to Enable. Then you can use the
Chargeable USB Port feature even in sleep mode.
7
Microphone Jack A jack used to connect the microphone.
8
Headphone Jack A jack used to connect the headphones.
