OPERATION
CONTROLLING TEMPERATURES
The refrigerator controls its temperature automatically. However, if needed, adjust the temperature as follows.
Freezer
compartment
• If the refrigerator is operated for a long time with
FREEZER TEMP. CONTROL set at 7(MAX),
foods stored in the refrigerator compartment may
also freeze.
Refrigerator
compartment
• If the refrigerator is operated for a long time with REFRIGERA-
TOR TEMP. CONTROL set at 7 (MAX), foods stored in the refrig-
erator compartment may also freeze.
• Low ambient temperature may cause placed foods to freeze even
if REFRIGERATOR TEMP. CONTROL is set to 1 (MIN).
HINTS WHEN MAKING ICE
1.The included Water supply cup can be used to
measure the amount of water to pour into Ice cube
trays. Pouring too much water into the tray will
result in the ice cubes connecting to each other
when frozen.
NOTE:
To prevent damage to the Ice cube box,
do not make ice in the Ice cube box or
pour oil into it.
Lever
Ice cube box
2.When the ice cubes are made, turn
the lever clockwise to empty the ice
into Ice cube box.
Amount for both Ice cube trays
Amount for one Ice cube tray
7(MAX)
4(MED)
1(MIN)
For making ice rapidly or fast
freezing.
When frozen food or ice cream is
not stored.
For normal freezing.
7(MAX)
4(MED)
1(MIN)
For keeping foods fresher tasting.
When the refrigerator does not provide sufficient
cooling.
For normal operation.
When the refrigerator provides excessive cooling.
MIN
MED
1
2
3
4
5
6
7
MAX
Coldest
REFRIGERATOR TEMP. CONTROL FREEZER TEMP. CONTROL
MIN MAX
MED
1
2
3
4 5
6
7
Coldest
1. To ensure adequate ventilation for your
refrigerator, it is recommended to provide
space of 6cm on both sides and at the
back, and space of 9cm above the refrig-
erator.
Insufficient spacing will decrease
the cooling efficiency, resulting in un-
necessary consumption of electricity.
INSTALLATION
NOTE:
• Keep your refrigerator out of direct sunlight.
• Do not place next to heat generating appliance.
• Do not place directly on the ground. Provide suitable stand.
When transporting
Carry the refrigerator by holding
the handles located on the rear
and bottom.
Before using your refrigerator
Clean the inside parts with a cloth
soaked in warm water. If soapy wa-
ter is used, wipe it off thoroughly.
6cm 6cm
9cm
148 cm
135 cm
6cm
Adjustable
foot
Evaporating
pan cover
2. Using the two front Adjustable feet, en-
sure that the refrigerator is positioned
firmly and level on the floor.
3. Clip Evaporating pan cover (supplied in-
side the refrigerator compartment) in po-
sition in front of the two Adjustable feet.
