11
CARE AND CLEANING
Some household cleaning chemicals may affect
the inside surfaces and plastic shelves resulting
in splitting or cracks occurring. Evaporating pan & cover;
How to remove
1.Hold both sides of Evapo-
rating pan cover and an-
gling upward.
2.Pull Evaporating pan out.
How to set
1.Put Evaporating pan on
Radiator plate, then slide
it in completely.
2.Fit the pawls of Evaporat-
ing pan cover into the
holes of the cabinet, then
push the cover to attach.
NOTE:
• Do not use polishing powder, benzine, hot water etc.
• If undiluted detergent is used or soapy water is not
wiped off thoroughly, cracking of plastic parts can re-
sult.
• Wipe any food oils adhered to plastic components
as they can cause cracking of the plastic surface.
• The glass shelves weighs approximately 3kg each.
Hold firmly when removing from the cabinet or carry-
ing. If you switch your refrigerator off when you are going away for
an extended period, remove all food, clean the interior thoroughly.
Remove the power cord plug from the power socket and leave
all doors open.
1.Remove the shelves and pockets from the cabinet
and door. Wash them in warm soapy dishwashing
water; rinse in clean water and dry.
2.Clean the inside with a cloth soaked in warm soapy
dishwashing water. Then, use cold water to wipe off
soapy water.
3.Wipe the exterior with a soft cloth each time it is
soiled.
4.Clean Magnetic door seal with a toothbrush and
warm soapy dishwashing water.
5.Evaporating pan should be removed and cleaned
once a year.
When cleaning all plastic parts in-
side this refrigerator, only use di-
luted dishwashing liquid(soapy
water). Make sure that all plastic
parts are thoroughly rinsed with
water after cleaning.
Switching off your refrigerator
WHAT TO DO BEFORE YOU CALL FOR SERVICE
Evaporating pan Evaporating pan
cover
Hole
Pawl
Before you call for service, check the following point.
IT IS NORMAL for the refrigerator to produce the
following sounds.
• Loud noise produced by the compressor when op-
eration starts --- Sound becomes quieter after a while.
• Loud noise produced once a day by the compressor
--- Operating sound produced immediately after au-
tomatic defrost operation.
• Sound of flowing fluid (gurgling sound, fizzing sound)
--- Sound of refrigerant flowing in pipes (sound may
become louder from time to time).
• Cracking or crunching sound --- Sound produced by expan-
sion and contraction of inner walls and internal parts during
cooling.
• Squeaking sound --- Sound produced by expansion and con-
traction of internal parts.
IT IS NORMAL that the outside of a cabinet may be hot when
touched. The hot pipe is in the cabinet in order to prevent dew
generation.
IF YOU STILL REQUIRE SERVICE
Refer to your nearest service agent approved by SHARP.
Replacing method of the lamp bulb
1.Unplug the refrigerator first to prevent elevtric shock.
2.Remove the light cover.
3.Replace the lamp bulb with the same type.
Freezer: base E12, MAX 10W, T-20
Refrigerator: base E12, MAX 15W, T-20
<Freezer> <Refrigerator>
Light cover
Light cover
