11 ASSEMBLING AND PREPARING
y Disconnect the power first, and then
move or install the TV. Otherwise electric
shock may occur.
y If you install the TV on a ceiling or slant-
ed wall, it may fall and result in severe
injury. Use an authorized LG wall mount
bracket and contact the local dealer or
qualified personnel.
y Do not over tighten the screws as this
may cause damage to the TV and void
your warranty.
y Use the screws and wall mount bracket
that meet the VESA standard. Any dam-
ages or injuries by misuse or using an
improper accessory are not covered by
the warranty.
CAUTION
y Use the screws that are listed on the
VESA standard screw specifications.
y The wall mount kit includes an installation
manual and necessary parts.
y The length of screws may differ depend-
ing on the wall mount. Make sure to use
the proper length.
y For more information, refer to the manual
supplied with the wall mount bracket.
NOTE
Mounting on a wall
Attach a wall mount bracket at the rear of the TV
carefully and install the wall mount bracket on a
solid wall perpendicular to the floor. When you
attach the TV to other building materials, please
contact qualified personnel.
LG recommends that wall mounting be performed
by a qualified professional installer.
Make sure to use screws and wall mount bracket
that meet the VESA standard. Standard dimen-
sions for the wall mount kits are described in the
following table.
Separate purchase(wall Mounting Bracket)
Model 32LV55**
32LV57**
32LW55**
32LW57**
32LW65**
37LV55**
37LV57**
37LW55**
37LW57**
VESA (A x B) 200 x 100 200 x 200
Standard screw M4 M6
Number of screws 4 4
wall mount
bracket
LSW100B,
LSW100BG
LSW200B,
LSW200BG
10 cm
10 cm
10 cm
10 cm
Model 42/47LV55**
42/47/55LV57**
42/47/55LW55**
42/47/55LW57**
42/47/55LW65**
42/47/55LW75**
42/47/55LW77**
47/55LW95**
72LZ97**
VESA (A x B) 400 x 400 600 x 400
Standard screw M6 M8
Number of screws 4 4
wall mount
bracket
LSW400B,
LSW400BG,
DSW400BG
LSW600B
A
B
