CONNECTING TO A TV
Setting your player
Step 1:connect the audio cables to AUDIO OUT of the DVD player.
Step 2:connect the yellow cable to the VIDEO on the side of your player.
(For TVs that support S-Video Output please follow the diagram “BETTER” bellow.)
GOOD
BETTER
Connect the portable DVD player with an optional S -Video cable, if the
TV has an S -Video input. Do not connect the yellow video cable if using
the S -Video cable.
Note:
l Turn off the power and unplug both units before setting up any connections.
TV Audio
Input/Output
TV
d o
Vi e
Input/Output
White
Red
Yellow
TV Audio
Input/Output
TV
d o
S-Vi e
Input/Output
White Red
Yellow
